Bandwidth-hungry ultra-high definition video, virtual reality, Internet of Things (IoT). An explosion of new devices and content. With these kinds of demands, organizations in every industry need more from their Wi-Fi. But with hundreds of devices and nonstop wireless noise and interference, busy indoor spaces can make challenging wireless environments.

The RUCKUS R560 is a mid-range Wi-Fi 6E tri-radio, tri-band concurrent indoor AP that delivers 6 spatial streams (2x2:2 concurrent in 2.4GHz, 5GHz, and 6GHz) and supports OFDMA, TWT and MUMIMO capabilities. It delivers industry-leading performance and reliability in demanding high-density environments with a combined data rate of 4.7 Gbps and efficiently managing up to 1536 clients. Furthermore, a 5 Gbps Ethernet port ensures the backhaul is not a bottleneck for full use of available Wi-Fi capacity.

Also, wireless requirements within enterprises are expanding beyond Wi-Fi. The R560 has built-in IoT radios with onboard BLE and Zigbee capabilities In -addition, the R560 is a converged access point that allows customers to seamlessly integrate any new wireless technologies with our USB port.

The R560 addresses the increasing client demands in transit hubs, auditoriums, conference centers, and other high traffic indoor spaces. It is the perfect choice for data-intensive streaming multimedia applications like 4K video transmissions, while supporting latency sensitive voice and data applications with stringent quality-of-service requirements.

The R560, with built-in RUCKUS exclusive technology, dramatically improves network performance through a combination of patented wireless innovations and learning algorithms that includes:

AirTme Decongestion: Increases average network throughput in heavily congested environments
Transient Client management: Reduces interference traffic from unconnected Wi-Fi devices
BeamFlex®+ Adaptive Antennas: Extended coverage range and optimized throughput with patented dynamic multi-directional antennas and radio patterns and work with any client.

Whether you are deploying ten or ten thousand APs, the R560 is also easy to manage through RUCKUS multiple management options including cloud based and on premises controllers.

Connect more devices simultaneously
: Improve device performance, by enabling more simultaneous device connections with built-in 6 spatial streams (2x2:2 concurrent in 2.4Ghz, 5GHz, and 6GHz), MU-MIMO and OFDMA technology.
High client density and performance
: Provides exceptional end-user experience within large meeting halls, general enterprise spaces, and large classrooms with a combined data rate of 4.7 Gbps.
BeamFlex+ Adaptive Antenna Technology
: For greater speed, fewer errors, and instant bandwidth delivery, RUCKUS BeamFlex+ patented technology offers first-of-its-kind smart antenna technology that maximizes signal coverage, throughput, and network capacity and work with any client. It further increases MIMO diversity gain and maximize spatial multiplexing potential.
Converged Access Point
: Allows customers to eliminate siloed networks and unify WiFi and non-WiFi wireless technologies into one single network by using built-in BLE and Zigbee, and also expanding to any future wireless technologies through the USB port.
5 GbE eliminates bottleneck:
Optimized multi-gigabit Wi-Fi performance delivered using the built-in 1/2.5/5GbE port to connect to multigigabit switches.
Multiple management options:
Manage the R560 with on premise physical/ virtual appliances and control auto-provisioning for faster deployment and seamless firmware upgrades.
Enhanced Security:
The latest Wi-Fi security standard with WPA3 andreceive enhanced protection from man-in-the-middle attacks. Adds the power of RUCKUS DPSK to WPA3/SAE combining enhanced security with the flexibility and ease of use of dynamic passphrase to secure network access
More Than Wi-Fi:
Support solutions beyond Wi-Fi with RUCKUS IoT Suite, RUCKUS Analytics RUCKUS Cloudpath Enrollment System and onboarding software
